34RS

Two channel receiver 12/24V AC/DC, 433,92MHz

34RS is the two channels receiver, 12V or 24 V AC/DC at frequency 433,92MHz. It is easy to be installed and controls high RF frequencies.

ProfelmNet

Main functions

  • Two channels receiver
  • Absorption 10mA max. at stand-by and 25mA on relay activation
  • Operation selectable PUSH-ON or PUSH ON-OFF with jumpers
  •  Power supply: 12-24V AC/DC in different models.
  •  Operating frequency 433,92MHz
  • Range from 30 to 100 meters depends on the environment
  • Sizes  82X59X30mm all with ABS housings
  •  Working temperatures: -15οC to + 60ο C



ProfelmNet

Available codes

Product name    Codification  Compatible Transmitters
PS34RS     fixed 433.92MHz  PSD-36T, PS-46T, LP-56T
PSR34RS keeloq rolling 433.92MHz PSR-38T, PSR-46T, PSR-25T, PSR-15T, S-18T,LP-56T
PN34RS pn rolling 433.92MHz PN-46T, LP-56T
